York ZF072 - Page 18

697890-YIM-C-0213
18 Johnson Controls Unitary Products
ZF072 - Without Powered Convenience Outlet (Belt Drive) Cooling With/Without Electric Heat
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
Max
Fuse
2
/
Breaker
3
Size
(Amps)
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
072
(6.0)
208-3-60 19.0 123.0 29.7 5.3 5.2 0.0
None - - - 34.3 45
E05 4.0 1 11.1 34.3 45
E07 5.6 1 15.5 34.3 45
E10 8.0 1 22.2 34.3 45
E15 11.9 2 33.0 47.8 50
E20 15.9 2 44.1 61.7 70
E30 22.2 2 61.6 83.5 90
230-3-60 19.0 123.0 29.7 5.3 5.2 0.0
None - - - 34.3 45
E05 5.3 1 12.7 34.3 45
E07 7.5 1 18.0 34.3 45
E10 10.6 1 25.5 38.4 50
E15 15.9 2 38.2 54.3 60
E20 21.2 2 51.0 70.2 80
E30 29.6 2 71.2 95.5 100
460-3-60 9.7 62.0 15.2 5.3 2.6 0.0
None - - - 17.4 25
E07 6.8 1 8.2 17.4 25
E10 10.1 1 12.1 18.4 25
E15 13.6 2 16.4 23.7 25
E20 19.5 2 23.5 32.6 35
E30 28.8 2 34.6 46.6 50
575-3-60 7.4 50.0 11.6 5.3 2.0 0.0
None - - - 13.4 15
E10 10.6 1 10.2 15.2 20
E15 15.9 1 15.3 21.6 25
E20 21.2 2 20.4 28.0 30
E30 30.4 2 29.3 39.1 40
ZF072 - Without Powered Convenience Outlet (Belt Drive) Cooling With Gas Heat
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
Max
Fuse
2
/
Breaker
3
Size
(Amps)
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
RLA LRA MCC FLA FLA FLA
072
(6.0)
208-3-60
19.0 123.0 29.7 2.3 5.2 0.0 31.3 40.0
230-3-60
460-3-60 9.7 62.0 15.2 1.3 2.6 0.0 16.0 25.0
575-3-60 7.4 50.0 11.6 1.3 2.0 0.0 12.3 15.0
