York ZF072 - Page 30

697890-YIM-C-0213
30 Johnson Controls Unitary Products
ZF072 - With Powered Convenience Outlet (Belt Drive High Static) Cooling With/Without Electric Heat
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
Max
Fuse
2
/
Breaker
3
Size
(Amps)
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
RLA LRA MCC FLA FLA FLA Model kW Stages Amps
072
(6.0)
208-3-60 19.0 123.0 29.7 5.3 10.9 10.0
None - - - 50.0 60
E05 4.0 1 11.1 50.0 60
E07 5.6 1 15.5 50.0 60
E10 8.0 1 22.2 53.9 60
E15 11.9 2 33.0 67.4 70
E20 15.9 2 44.1 81.3 90
E30 22.2 2 61.6 103.2 110
230-3-60 19.0 123.0 29.7 5.3 10.9 10.0
None - - - 50.0 60
E05 5.3 1 12.7 50.0 60
E07 7.5 1 18.0 50.0 60
E10 10.6 1 25.5 58.0 60
E15 15.9 2 38.2 73.9 80
E20 21.2 2 51.0 89.9 90
E30 29.6 2 71.2 115.1 125
460-3-60 9.7 62.0 15.2 5.3 5.3 5.0
None - - - 25.1 30
E07 6.8 1 8.2 25.1 30
E10 10.1 1 12.1 28.1 30
E15 13.6 2 16.4 33.3 35
E20 19.5 2 23.5 42.2 45
E30 28.8 2 34.6 56.2 60
575-3-60 7.4 50.0 11.6 5.3 4.1 4.0
None - - - 19.5 25
E10 10.6 1 10.2 22.9 25
E15 15.9 1 15.3 29.2 30
E20 21.2 2 20.4 35.6 40
E30 30.4 2 29.3 46.7 50
ZF072 - With Powered Convenience Outlet (Belt Drive High Static) Cooling With Gas Heat
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Conv
Outlet
MCA
1
(Amps)
1. Minimum Circuit Ampacity.
Max
Fuse
2
/
Breaker
3
Size
(Amps)
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
RLA LRA MCC FLA FLA FLA
072
(6.0)
208-3-60
19.0 123.0 29.7 2.3 10.9 10.0 47.0 60.0
230-3-60
460-3-60 9.7 62.0 15.2 1.3 5.3 5.0 23.7 30.0
575-3-60 7.4 50.0 11.6 1.3 4.1 4.0 18.4 25.0
