York ZF072 - Page 35

697890-YIM-C-0213
Johnson Controls Unitary Products 35
CONDENSER FAN DATA
Quantity 1 1 1
Fan diameter (Inch) 24 24 24
Type Prop Prop Prop
Drive type Direct Drive Direct Drive Direct Drive
Quantity of motors 1 1 1
Motor HP each 1/2 1/2 1/2
No. speeds 1 1 1
RPM 1090 1090 1090
Nominal total CFM 3800 4200 4200
BELT DRIVE EVAP FAN DATA
Quantity 1 1 1
Fan Size (Inch) 12 x 10 12 x 10 12 x 10
Type Centrifugal Centrifugal Centrifugal
Motor Sheave 1VL44 1VP56 1VL44 1VP56 1VL44 1VP56
Blower Sheave AK64 AK66 AK56 AK61 AK56 AK56
Belt A37 A39 A36 A38 A36 A38
Motor HP each 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 2
RPM 1725 1725 1725
Frame size 56 56 56
DIRECT DRIVE EVAP FAN DATA
Quantity 1 1 1
Fan Size (Inch) 12 x 10 12 x 10 12 x 10
Type Centrifugal Centrifugal Centrifugal
Motor HP each 1/2 1 1
RPM 1050 1050 1050
FILTERS
15” x 20” x 1” or 2” 2 2 2
14” x 25” x 1” or 2” 1 1 1
NOTE: All 2 Stage Gas Heat, 60% Capacity 1
st
Stage, 40% Capacity 2
nd
Stage.
ZF036-060 Physical Data (Continued)
Component
Models
ZF036 ZF048 ZF060
Nominal Tonnage 3.0 4.0 5.0
