2.3.6 Probe outline dimensions and weight
Convex array size: 166mm (L) * 58mm (W) * 24mm (thickness)
Net weight: 235g (R50) (C5-2Fs)
Convex array size: 167mm (L) * 58mm (W) * 24mm (thickness)
Net weight: 260g (R60) (C5-2Ks)
Linear array size: 159mm (L) * 58mm (W) * 24mm (thickness)
Net weight: 225g (L40) (L11-4Ks)
Linear array size: 159mm (L) *58mm (W) * 24mm (thickness)
Net weight: 220g (L25) (L11-4Gs)
Slightly Convex array size: 160mm (L) * 58mm (W) * 24mm (thickness)
Net weight: 230g (R15) (C8-5Ks)
2.4 system configuration
The system is mainly composed of main unit equipment, transduser and application
(Android/Windows platform )
The configurable probe model is:C5-2Fs(Convex array)，C5-2Ks(Convex array)，L11-4Ks(Linear
array)， L11-4Gs(Linear array)，C8-5Ks(Slightly Convex array)
2.4.1 Standard configuration
Main unit: 1 set
Appendix
condensation in the circuit board, there is the risk of short
circuit.
3. Do not operate the unit in an environment with flammable or
explosive liquids, vapors or gases such as oxygen or hydrogen. Do
not use the scanner in an environment containing combustible gas,
such as an anesthetic gas, hydrogen, or flammable liquid, such as
ethanol. It may cause an explosion..
A. If there are flammable substances in the environment, do not
use the scanner.
B. Use the real-time detection environment to detect flammable
substances after the system is turned on. Do not attempt to turn
off the device or unplug the power supply. First empty the air in
the area and ensure a smooth ventilation and then turn off the
power.
4. If the system fails, please do not disassemble the scanner,
please contact the service center or your sales representative.
