Young Electric Sole - Product Components and Tools; Parts List; Required Tools

Parts Parts List
Requied Tools（Not included）
Name Imperial Metric
Monkey Wrench 12’’ 300mm
Open Wrench 7/16’’ 11mm
Open Wrench 11/16’’ 17mm
Part# Description Qty
1 Beam Assembly 1
2 M10 Outer Hexagon Bolt 4
3 Front Wheel Mount 1
4 M10 Long Outer Hexagon Bolt 2
5 M10 Lock Nut 3
6 Bottom Fixing Bracket 1
7 Support Rod 1
8 M10 Low Square Neck Bolt 1
9 Adjustable Support Assembly 1
10 M16 Shockproof Bolt 1
11
φ16 Spring Washer
1
12
φ16 Flat Washer
1
13
φ3.8 Cotter Pin/Lock
1
1
2
x
x
x
3
4
x
x
x
5
x
x
x
8
x
x
x
6
x
x
x
7
x
x
x
9
x
x
x
1
0
1
0
1
0
1
0
10
11
12
13
