STEP7-A). Connect 8 pin connectors by carefully sliding connector with plastic
extrusion under plastic clip on second connector.
STEP7-B). Attach the Button Control Panel (A1), and secure using Screw (510).
STEP7-C). Use Screw (512) to hold the Button Control Panel on left and right side to
the corresponding hole in plastic.
