STEP2-A). Connect the 8pin Power Wire – Upper (613) to 8pin Power Wire – Middle
(614) and Safety Key Wire – Upper (628) to Safety Key Wire – Middle (629).
STEP2-B). Attach the Console Support Tube to the Upright and Attach the Handlebar
(A3, A4) to the Console Support Tube.
STEP2-C). Using the Allen Head Bolt (901) to secure the Handlebar and
Console Support Tube to the Upright.
