8
BALANCED/UNBALANCED SWITCH
When using the RCA connector turn the switch located on the back panel of the amplifier
to the UNBALANCED position. This is the input the manufacturer recommends.
NEVER use RCA inputs with the switch turned to BALANCED position.
When using the XLR input turn the switch to the BALANCED position .This is
recommended when using long cables from the pre amplifier.
GROUND/LIFT SWITCH
When the switch located on the back panel is turned to the LIFT position the ground
circuit is disconnected from chassis ground. This is used to eliminate ground loop in the
system and hum in the speakers. This is the recommended position.
When the switch is turned to the GROUND position the circuit ground is connected to
the chassis ground.
BALANCED/
UNBALANCED
SWITCH
GROUND/
LIFT
SWITCH
