Yuanxin Electric YX3300 User Manual

YX3000 Senseless Vector Type Inverter Manual
- 55 -
Chapter 5 Function Parameter Table
5.1 Symbol Description
“○”: means that the parameter can be modified during running state.
“×”: means that the parameter can not be modified during running state.
“*”: means read-only parameter which can not be modified.
5.2 Function Code Table
P0 Group: Basic running function parameter
Func
Code
Name
Range
Min
Unit
Factory
Default
Modify
P0.00
Control mode
selection
0：V/F Control
1：Senseless vector control
1
0
○
P0.01
Freq control
channel selection
0：Analog potentiometer on control panel
1：▲、▼key on control panel
2：Digital setting 1,control panel given
3：Digital setting 2, UP/DOWN terminal
given
4：Digital setting 3, serial port given
5：VI analog given
(VI-GND)
6：CI analog given(CI-GND)
7：Pulse terminal given(PULSE)
8：Combination given (refer to P3.00)
1
0
○
P0.02
Running frequency
set
P0.19lower limit freq.~P0.20upper limit
freq.
0.01H
Z
50.00HZ
○
P0.03
Running command
mode selection
0：Control panel mode
1：Terminal control mode
2：Serial port control mode
1
0
○
P0.04
Running direction
setting
Unit’s digit: 0: Forward 1:Reverse
Ten’s digit: 0:REV allowed 1:REV
prohibited
1
10
○
P0.05
FWD/REV dead
time
0.0～120.0s
0.1s
0.1s
○
P0.06
Max output freq.
50.00Hz～500.00Hz
0.01H
z
50.00Hz
×
P0.07
Basic running freq
1.00Hz～500.00Hz
0.01H
z
50.00Hz
×
