Page #3 background imageLoading...
Page #3 background image
Yudian(H.K.)AutomationTechnol o gyCo.Ltd.
Website:http://www.yudian.ushttp://www.yudian.com.hk
Email:sales@yudian.com.hk
Tel:+85227708785Fax:+85227708796
3
ORDERING CODE:
The ordering code of AI-501 is made up of 8 parts, for example:
AI-501
A N X3 L5 N S4 24VDC
② ③ ④ ⑤ ⑥ ⑦ ⑧
This means an instrument with model AI-501, dimension A (96x96mm), no module in MIO (multiple
input/output) slot, X3 linear current output module installed in OUTP (main output) slot, L5 dual relay output
module in ALM (alarm) slot, no module in AUX (auxiliary output), RS485 communication interface module S4
in COMM (communication) slot, and 24VDC power supply.
The meanings of the 8 parts of ordering code are as below:
Shows the model of instrument
AI-501 Indicating/Alarming Instrument with measurement accuracy of 0.3%FS
Shows the front panel dimension:
Size
Front Panel
Width X Height
Cut Out
Width X height
Depth Behind Light Bar
A 96 X 96 mm 92 X 92 mm 100 mm No
A2 96 X 96 mm 92 X 92 mm 100 mm 25 segments and 4 levels
B 160 X 80 mm 152 X 76mm 100 mm No
C 80 X 160 mm 76 X 152mm 100 mm No
C3 80 X 160 mm 76 X 152mm 100 mm 50 segments and 2 levels
D 72 X 72 mm 68 X 68 mm 95 mm No
E 48 X 96 mm 45 X 92 mm 100 mm No
F 96 x 48 mm 92 X 45 mm 100 mm No
D2 48 X 48 mm 45 X 45 mm 95 mm No
Shows the module types of multiple input/output (MIO). Selectable modules are as follows:
V5/V10 Isolated 5 /12 /10 /24VDC voltage output, can supply power for external transmitter or transducer.
V12 / V24
I4 4-20mA or 0-20mA analogue input interface with 24VDC/50mA power supply, can directly
connect to two-wire transmitter
I7 0~5A current input module, can measure 5A alternating current directly.
I8 0~500V voltage input module, can measure 0~500VAC alternating voltage directly
Shows the module types of main output (OUTP):
Installing X3 or X5 (isolated type) current output module can retransmit process value (PV).
Shows the module type of alarm output (ALM):
Can output alarms by installing L1, L2, or L4 relay output module or L5 dual relay output module.
Shows the module type of auxiliary output (AUX):
