YUHAO 1163 - Step 3: Receiver and Wiring Installation

Step 3 (Receiver and wiring installation)
②
③
Put the receiver into the Bracket and
arrange the wires
Adjust the position of Canopy, then
lock it
①
Installation Instruction
Connect the Connectors from Fan and Receiver. Connect the wires from the receiver
to House Supply Wire.
Safety rope installation method
Safety rope
.7.
Visit www.pmwfan.com for further assistance.
House power
To Light To Motor
Ground wire
AC IN L( Black )
AC IN N(
White )
