YUNEEC E-GO2 - Garage

DRIVE WHEEL
AND BELT
DEFORMING THE DRIVE
BELT MIGHT DAMAGE IT.
GARAGE
front truck screws
battery pack screws
ECU screws
rear truck screws
1.
2.
3.
4.
motor cover
drive belt cover
drive belt cover screw
drive belt
drive wheel
washer
drive wheel nut
5.
6.
7.
8.
9.
10.
11.
3
2
1
4
5
8
9
10
11
7
6
10
DECK
SCREWS
20
MAKE SURE THE E-GO2 IS POWERED
OFF WHEN DOING MAINTENANCE
OR REPLACING COMPONENTS.
