INSTALLATION GUIDE
BEARING SET (8 PCS)
EGOCR007
1 Unscrew the wheel bolt. 2 Dismount
the wheel from the truck's axle.
3 Replace the bearing in the wheel
with the spare part by applying equal
pressure on the outer rings of the
bearings.
4 Mount the wheel back
onto the truck axle.
5 Screw on the
wheel nut and tighten.
MOTOR COVER EGOCR003
1 Unscrew the five screws securing
the motor cover.
2 Remove the motor
cover and replace it with the replace-
ment part.
3 Screw on the motor
cover screws and tighten.
DRIVE BELT EGOCR004
1 Unscrew the drive wheel bolt.
2 Dismount the rear wheels from the
trucks axle.
3 Unscrew the drive belt
cover screws.
4 Replace the belt with
the replacement part.
5 Screw on and
tighten the drive belt cover screws.
6 Mount the drive wheel back onto the
truck's axle.
7 Screw on the drive wheel
nut and tighten.
WHEEL SET WITH PRE-
INSTALLED BEARINGS
EGO2CR005, EGO2CR006 AND EGO2CR007
1 Unscrew the wheel bolt. 2 Dismount
the wheel from the truck's axle and
replace it with the replacement part.
3 Screw on and tighten the wheel bolts.
BUSHING SET EGOCR005
1 Unscrew the kingpin nut from the
kingpin.
2 Replace the bushing.
3 Remount the truck and bushing on
the baseplate axle.
4 Screw on and
tighten the king pin nut.
E-GO2
THIS MANUAL IS SUBJECT TO CHANGE
WITH FUTURE REVISIONS.
> PLEASE VISIT WWW.YUNEEC.COM
BATTERY PACK EGO2CR018SVC,
EGO2CR019SVC AND EGO2CR020SVC
1 Unscrew the screws connecting the
battery pack to the deck.
2 Tilt the
battery pack out of its slot with the
ECU.
3 Disconnect the wires connec-
ting the battery pack to the ECU and
reconnect the ECU's wires to the replace-
ment part.
4 Slide the replacement part
in its slot with the ECU.
5 Screw in the
deck screws connecting the battery
pack to the deck.
