Print head not seated correctly
+
Re-seat pen and restart build
Pogo pin / pins are bent or broken
-
Change pogo card (See 08632 Benchwork manual)
Head card ribbon cable disconnected at either end
-
Check head card ribbon cable connections
Error 1002 Message
(Rom read failed for head)
Tape still in place over print head contacts - Remove tape and re-install pen
Print head failure, bad smart chip - Print head failure, bad smart chip
Error 1003 Message
(I2C read failed for head)
Pogo card malfunction
+
Inspect pogo cards. Pins should be clean and not
bent or broken
Flash card not connected to ATX power supply
+
Check power connection to flash card
Bad PCI card
+
Replace PCI Card
(See 08632 Benchwork manual)
Flash card corrupt or erased
-
Replace flash card or check master slave switch
Dead CMOS battery on motherboard
-
Change CMOS battery.
(See 08632 Benchwork manual)
Voltage selector set wrong on power supply (selector
set to 230V with 110V input)
-
Unplug printer and set selector to proper voltage
PCI Card not seated properly
-
Check PCI to motherboard connection
Machine will not boot or
come online
(Power LED is on)
PCI EEPROM chip not seated or bad
-
Re-seat or replace EPROM chip
Interlock switch not connected to Igus harness properly
or malfunctioning interlock switch
+
Check connection to switch or replace switch
(See 08632 Benchwork manual)
Online / Error lights flash
and long sustained beep
Bad PCI card
-
Replace PCI Card
(See 08632 Benchwork manual)
Binder dripping onto top
deck
Septum / barb fitting leaking or binder tubing not
properly inserted onto barb fitting at print head
+
Replace septum if necessary. Check tubing
connection at barb fitting
Power cable not connected to middle connector on the
PCI card
+
Check connection at PCI card.
Slow Axis bearings low on grease or seized
+
Grease slow axis bearings or replace slow axis
bearings if necessary.
Slow Axis cable disconnected or forced on backward
-
Check slow axis cable connection
Slow Axis motor failure
-
Replace slow axis motor.
(See 08632 Benchwork manual)
Error 2303(0) message
(Axis excessive position
error)
Slow Axis idler pulley seized
-
Change Slow Axis idler
(See 08632 Benchwork manual)
