3
GATEWAY MODULE INSTALLATION
1. Remove the push pins holding the passenger
side carpet silencer panel in place.
The security gateway module
is located on the passenger
side under the glove box.
1. Remove the panel to access under the dash.
2. You can remove the 3 screws and remove the entire
module. Or reach your hand behind and remove the
plugs from the module.
2. Remove both connectors plugged into security
gateway module.
3. Remove the two plugs in the security module and reconnect
to the bypass module.
*You must remove the Z-Flash Bypass Module and reconnect
the Chrysler Security Module when servicing your vehicle
to ensure the dealer tool will operate.
3. Remove the two plugs in the security module and reconnect
to the bypass module.
*You must remove the Z-Flash Bypass Module and reconnect
the Chrysler Security Module when servicing your vehicle
to ensure the dealer tool will operate.
2018-2020 Jeep Grand Cherokee
2018-2020 Durango
2019-2020 Ram 1500
2018-2020 Charger
2018-2020 Wrangler JL
2018-2020 300
2020 Jeep Gladiator
