ZaapTV HD509N - Appearance and Components; Front Panel Overview; Side Panel Ports; Rear Panel Connections

2 Appearance
HD509N-User’s Guide 4
Front Panel
1. Power indicator
Side Panel
Rear Panel
1
1.USB 2.USB 3.USB
1
2
3
4
5
8
7
1. WiFi antenna
2.
3. A/V out
4. Optical fiber out
5. Reset key
6. TF card
7. RJ45 network interface
8. HDMI out
9. POWER
6
9
1
2 3
