ZALMAN CNPS10X Flex - AMD Socket 754;939;940 Installation

10
.COM
ENGLISH
3) AMD Socket 754 / 939 / 940 Installation
① Spread about 1/3 of the included
Thermal Grease on the CPU.
② Center the Cooler on top of the CPU and press down on the Clip Lever
after fastening the AMD B Clip’s Square End to the Clip Support Lug Slot.
Square End
Lug Slot
③ Attach the Vibration Pads to the cooler and use the Fixing Clips to install
one or two fans.
