ZALMAN Z9 series User Manual

4
Z9 Series
(4) Parts
Cable Tie × 5 CPU 12V Extension Cable × 1
Stand-O󰘯 × 5Main Unit
A Bolt (#6-32*6mm) × 11
[PSU, PCI]
B Bolt (M3*5mm) × 17
[M/B, FDD, SSD]
D Bolt (#6-32*4mm) × 20
[3.5” Bay HDD]
C Bolt (M3*6mm) × 12
[5.25”Bay ODD]
HDD Anti-static rubber × 20
[3.5” Bay HDD]
User’s Manual
E Bolt (#6-32*6mm) × 5
[3.5” HDD]

ZALMAN Z9 series Specifications

General

Motherboard Support	ATX, Micro-ATX, Mini-ITX
Material	Steel, Plastic
Expansion Slots	7
Maximum GPU Length	290mm
Maximum CPU Cooler Height	160mm
Color	Black
Type	Mid Tower
Drive Bays	External 5.25" x 4, Internal 3.5" x 5, Internal 2.5" x 1
Cooling System	Front: 1 x 120mm fan (included), Rear: 1 x 120mm fan (included), Top: 2 x 120mm fan (optional)
Front I/O Ports	2 x USB 2.0, 1 x USB 3.0
