7
ENG
Z9 Series
(3) Motherboard Installation
ATX Board
or
m-ATX Board
There are 4 Stand O󰘯s preinstalled. Please refer to the diagrams below for
additional Stand O󰘯 positions (based on motherboard type).
Stand-O󰘯
B Bolt
