2
●Advanced MCU control pulse width modulated (PWM) technology, high efficiency
operation.
●
for LiFePO4, LTO (Lithium Titanium Oxide), LI-95, Gel, AGM, Conventional
lead-acid (WET) Batteries.
●Integrated regulator to prevent your battery from being overcharged. Overcharging
occurs when the charge voltage is unregulated. This can result in premature battery
failure.
●Integrated regulator to prevent your battery from being under charged, The unit
provides an automatic Equalization feature for deeply drained Conventional lead
acid battery, as well as provides a cycling automatic Equalizing feature every 28
days.
●Can be connected to the battery permanently to keep the battery fully charged by
using a process called “floating”. This means the controller will stop charging when
the battery is full and will automatically start charging the battery as required. This
process will also reduce water loss and help prevent the battery from ‘drying out’.
●Protects your battery from discharge at night. Under low light or no light conditions
the solar panel voltage could be less than the battery voltage. The unit contains a
special circuit which pr
events current flowing back from the battery and into the
solar panel.
●Colored LED’s to easily indicate the operational status and battery conditions.
●Digital LCD to directly display battery voltage, charging current, charging capacity
(Amp hour), battery types and faulty codes.
●Provides plug-in remote digital display meter (Optional).
●Provides external battery temperature sensor (Optional).
●Multi charging protections against reverse polarity, short circuit, over temperature,
over voltage, etc.
●Surface Mount or Flush Panel Mount options.
●Conformal-coating circuit boards and plated terminals apply to hostile environments.
For use with 12/24Volt Solar Panel; Suitable for Solar panels up to
760 Watts on 12V mode; 1520Watt on 24V mode
FEATURE
SCC1011
