Zap HSM-B131B User Manual

4
4. Install the Left and Right Pedals.
Attach the left/right pedal onto corresponding axles (left
pedal with left-hand thread, right pedal with right-hand
thread).
5. Install the Back Handlebar and Seat Cushion.
Loose the nylon nut and washer, place the back handlebar
onto the triangle plate and tighten.
Place the seat cushion onto the plate and tighten.
6. Install the Seat Post.
Place the seat post onto the main frame and tighten.
NOTE: When adjusting the height of seat post, the
maximum insert depth of mark line
cannot be higher than the edge of b
ushing.
