ZCS Azzurro 3PH HYD15000 ZSS User Manual

User Manual 3PH HYD5000-HYD20000-ZSS
Rev. 1.1 16/03/2021
Identification: MD-AL-GI-00
Rev. 1. of 16/03/2021 - Application: GID
109/138
battery and inverter for any errors.
ID161
ForceShutdown
Forced shutdown
The inverter has undergone a forced
shutdown
ID162
RemoteShutdown
Remote shutdown
The inverter has undergone a forced
remote shutdown
ID163
Drms0Shutdown
DRMs0 shutdown
The inverter has undergone a forced
DRMs0 shutdown
ID165
RemoteDerating
Remote derating
The inverter has undergone a remote
load derating
ID166
LogicInterfaceDer
ating
Logic interface derating
The inverter is loaded by running the
logic interface.
ID167
AlarmAntiRefluxin
g
Anti-reflux derating
The inverter is programmed to
prevent counter-current load
sagging.
ID169
FanFault1
Fan1 error
Check whether fan 1 of the inverter is
working properly
ID170
FanFault2
Fan2 error
Check whether fan 2 of the inverter is
working properly
ID171
FanFault3
Fan3 error
Check whether fan 3 of the inverter is
working properly
ID172
FanFault4
Fan4 error
Check whether fan 4 of the inverter is
working properly
ID173
FanFault5
Fan5 error
Check whether fan 5 of the inverter is
working properly
ID174
FanFault6
Fan6 error
Check whether fan 6 of the inverter is
working properly
ID177
BMS OVP
BMS overvoltage alarm
Internal lithium battery error; turn
off the inverter and battery, wait 5
minutes and then turn them on again.
If the errors still occur, contact
technical support
ID178
BMS UVP
BMS undervoltage alarm
ID179
BMS OTP
BMS high temperature
alarm
ID180
BMS UTP
BMS low temperature
alarm
ID181
BMS OCP
BMS overload warning
when charging and
discharging
ID182
BMS Short
BMS short-circuit alarm

ZCS Azzurro 3PH HYD15000 ZSS Specifications

General

Max. DC Voltage	1000 V
Number of MPPTs	2
Max. AC Power	15000 W
Nominal AC Voltage	400 V
Battery Voltage	48 V
Max. Charging/Discharging Current	200 A
Protection Degree	IP65
Output Power	15000 W
Type	Hybrid
Model	ZCS Azzurro 3PH HYD15000 ZSS
Phase	Three Phase
