Zebex Z-3151HS - Page 72

Advanced Handheld High-Speed Laser Scanner
66
USER’S MANUAL
Example
If the barcode data transmission sequence and requirements are as below:
Start of Configuration
Set up the 1
st
barcode
symbology
Set up the 2
nd
barcode
symbology
End of Configuration
The 1
st
barcode symbology The 2
nd
barcode symbology
Barcode type Code 128 Barcode type
Code 39
Barcode length 9 Barcode length 12
First digit A First digit
No check on the first digit is
required
Start
Set up data transmission sequence
and re
q
uirement
End
Barcode type:
Code 128
Barcode type:
Code 39
End of configuration
Start of configuration
Multi-barcode
enable
The first digit
A
The first digit
NUL
Length: 9
0
9
Set
Length: 12
1
2
Set
Full ASCII code 39
Start to edit multi-
barcode
