Quick Start Guide 11
Figure 3 Pick List Mode with Multiple Bar Codes in Aiming Pattern
5. The Data Capture LED lights green and a beep sounds, by default, to indicate the bar code was decoded successfully.
6. Release the scan button.
7. The bar code content data displays in the text field.
Ergonomic Considerations
Figure 4 Ergonomic Considerations
NOTE Imager decoding usually occurs instantaneously. The TC51 repeats the steps required to take a digital picture (image) of a poor
or difficult bar code as long as the scan button remains pressed.
AVOID EXTREME
WRIST ANGLES
