Zebra WT6300 User Manual

WT6300 Wearable Computer Quick Start Guide
10
Charging Temperature
Charge batteries in temperatures from 0°C to 40°C (32°F to 104°F). The device or cradle always performs
battery charging in a safe and intelligent manner. At higher temperatures (for example, approximately
+37°C (+98°F)) the device or cradle may for small periods of time alternately enable and disable battery
charging to keep the battery at acceptable temperatures. The device and cradle indicates when charging is
disabled due to abnormal temperatures via its LED.
Solid Green Battery charging is complete.
Fast Blinking Red
(2 blinks/second)
Charging error, for example:
- Temperature is too low or too high.
- Charging has gone on too long without completion (typically eight hours).
Solid Red Unhealthy battery is charging or fully charged.
Table 2 Charging LED Indicators (Continued)
State Indication

Zebra WT6300 Specifications

General

Display diagonal	3.2 \
Touchscreen type	Capacitive
Display resolution	800 x 480 pixels
USB 2.0 ports quantity	1
Flash memory	32 GB
Internal memory	3 GB
Internal memory type	-
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	2.2 GHz
Processor manufacturer	Qualcomm
Battery capacity	5000 mAh
Operating system version	11
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Security algorithms	EAP-PWD, EAP-TLS, EAP-TTLS, FIPS 140-2, LEAP, PEAP, WEP, WPA, WPA-Enterprise, WPA2-Enterprise, WPA3, WPA3-Enterprise
Product color	Black
International Protection (IP) code	IP65
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Speakers	Mono
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	121 mm
Width	89 mm
Height	34 mm
Weight	256 g
