Zebra Z4M/Z6M Printers User’s Guide 51
Label Positioning Parameters
Display Shows Action/Explanation
BACKFEED
Backfeed Sequence: Press the INCREMENT (+) or DECREMENT (–) key to
display other choices.
Default: Default (90%)
Selections: Default, after, before, 10%, 20%, 30%, 40%, 50%, 60%, 70%,
80%, off
This parameter establishes when and how much label backfeed occurs after a
label is removed or cut in the peel-off or cutter modes. It has no effect in rewind
or tear-off modes. This parameter setting can be superseded by the ~JS
instruction when received as part of a label format (refer to the ZPL II
Programming Guide Volume I).
NOTE: The difference between the value entered and 100% establishes how
much backfeed occurs before the next label is printed. For example, a
value of 40 means that 40% of the backfeed takes place after the label is
removed or cut. The remaining 60% takes place before the next label is
printed. A value of “before” means that all backfeed takes place before
the next label is printed.
LABEL TOP
Adjusting Label Top Position: Press the INCREMENT (+) key to increase the
value, press the DECREMENT (–) key to decrease the value. The displayed
value represents dots.
Default: +0
Range: –120 to +120 dot rows
The label top position adjusts the print position vertically on the label. Positive
numbers adjust the label top position further down the label (away from the
printhead); negative numbers adjust the position up the label (toward the
printhead).
LEFT POSITION
Adjusting Left Position: Press the DECREMENT (–) key to move to the next
position, press the INCREMENT (+) key to change between + and – and to
increase the value of the digit. The displayed value represents dots.
Default: 0000
Range: –9999 to +9999
NOTE: For a negative value, enter the value before changing to the minus
sign.
This parameter establishes how far from the left edge of a label the format
begins to print by adjusting horizontal positioning on the label. Positive numbers
adjust the printing to the left by the number of dots selected; negative numbers
shift printing to the right.
