Printer Features
2
P1061739-002 ZD500 Quick Reference Guide 01/23/2014
Figure 2 • Printer Features Continued
Sensor
Peel Bar
Platen
Roller
Printhead
Moveable
BlackLine
Sensor
Ribbon Trailer Sensor
(hidden from view)
Roll Holders and
Media Guides
Head-Up Sensor
(inside)
Pinch
Roller
Dispenser Door
(open)
Take Up Spindles
Supply Spindles
Ribbon Roll Holders
Dispenser Option
Web (Gap)
Sensor
Media Guide Stop
Adjustment
RFID Antenna
(inside)
