Need help?Do you have a question about the Zebra ZM400 and is the answer not in the manual?
Printer Specifications| resolution | 203 dpi/8 dots per mm, 300 dpi/12 dots per mm, 600 dpi/24 dots per mm |
|---|---|
| print width | 4.09”/104 mm |
| print length | 157”/3, 988 mm with 203 dpi, 73”/1, 854 mm with 300 dpi, 39”/991 mm with 600 dpi |
| maximum label and liner width | 4.5”/114 mm |
| ribbon width | 2.00”/51 mm to 4.33”/110 mm |
Environmental| operating temperature | 32º F/0º C to 104º F/40º C (Direct Thermal), 40º F/5º C to 104º F/40º C (Thermal Transfer) |
|---|---|
| storage temperature | -40º F/-40º C to 140º F/60º C |
| operating humidity | 20-85% non-condensing |
| storage humidity | 5-85% non-condensing |
Weight and Dimensions| width | 10.9”/278 mm |
|---|---|
| height | 13.3”/338 mm |
| depth | 18.7”/475 mm |
| weight | 32.4 lbs/15 kg |
| shipping weight | 49 lbs/22 kg |
Printer Specifications| resolution | 203 dpi/8 dots per mm, 300 dpi/12 dots per mm |
|---|---|
| print width | 6.6”/168 mm |
| print length | 102”/2, 590 mm with 203 dpi, 45”/1, 143 mm with 300 dpi |
| maximum label and liner width | 7.0”/178 mm |
| ribbon width | 2.00”/51 mm to 6.85”/174 mm |
Environmental| operating temperature | 32º F/0º C to 104º F/40º C (Direct Thermal), 40º F/5º C to 104º F/40º C (Thermal Transfer) |
|---|---|
| storage temperature | -40º F/-40º C to 140º F/60º C |
| operating humidity | 20-85% non-condensing |
| storage humidity | 5-85% non-condensing |
Weight and Dimensions| width | 10.9”/278 mm |
|---|---|
| height | 13.3”/338 mm |
| depth | 18.7”/475 mm |
| weight | 32.4 lbs/15 kg |
| shipping weight | 49 lbs/22 kg |
