11
Load Media and Ribbon
4/8/14 ZT400™ Series Quick Reference Guide P1060608-003
7. From the media hanger (1), feed the media under the dancer assembly (2), through the
media sensor (
3), and under the printhead assembly (4). Slide the media back until it
touches the inside back wall of the media sensor.
8. Slide in the media guide until it just touches the edge of the media.
To Next Page
