6 Technical data
Optical data, Sharp Max
Collimator: achromat, f =200mm
Exit pupil: 50mm
Siemens star: 72 sectors, smallest grating constant approx. 4.4µm
Illumination: green LEDs, λ 570nm, adjustable brightness and illumination-ON period
Admissible testpiece data
Focal length: 5mm to 70mm
Ambient conditions
Temperature range: -20°C to +40°C
Power supply
9V block battery, 6LR 61 type, alternatively 9V NiCd rechargeable battery
or external 12V DC / 100mA power source
Options
Lens flange for lenses from other manufacturers
Subject to change.
