Depressing the SELECT DISPLAY button displays the
END TECH SET PTS display.
END TECH SET PTS
SELECT
DISPLAY
At the end of the list of parameters, depressing the
SELECT DISPLAY button displays the beginning of the
ALARM LIST.
BEGIN ALARM LIST
SELECT
DISPLAY
Depressing the SELECT DISPLAY button displays the
alarms that the dryer has experienced, with the most
recent alarm displayed first. The actual display will
depend on the most recent alarm detected by the DPC.
HPCO ALARM
SELECT
DISPLAY
The list of alarms can be scrolled by depressing the
SELECT DISPLAY button as needed. At the end of the
alarm list, the END ALARM LIST screen is displayed.
END ALARM LIST
SELECT
DISPLAY
Depressing the SELECT DISPLAY list displays the
ALARM LIST screen at the top of the ALARM LIST.
BEGIN ALARM LIST
SELECT
DISPLAY
The Alarm List will repeat as long as the SELECT DISPLAY button is depressed.
To EXIT the ALARM LIST, perform the following:
Depressing the BLANK button (located above the SET
button) returns the controller to the top of the TECHNI-
CIAN MODE.
TECH SET MODE
Depressing the BLANK button again returns the controller
to the default display of the CUSTOMER MODE.
CHLLR TEMP: 37
Changing the AUTO RESTART feature to “Y” will permit the dryer to operate automati-
cally once power is applied and after a brief delay. Proper warning signs should be
affixed to the dryer to alert users and service personnel that dryer may start without
warning. Failure to do so may result in serious injury.
The remaining non-adjustable parameters may be viewed by depressing the SELECT
DISPLAY button as required to arrive at the desired display. .
To exit the TECHNICIAN MODE at any time, depress the “BLANK” button located
above the SET button to return to the CUSTOMER MODE.
9.2 ALARM LIST
At the end of the list of non-adjustable parameters, the DPC™ displays a list of the
most recent 20 alarm conditions. This list can facilitate troubleshooting the dryer
NOTICE
22
WARNING
