Specification information above accurate at time of publication. Refer to equip-
ment serial label for actual refrigerant charges and specifications for units.
14. ENGINEERING SPECIFICATIONS
33
Maximum Allowable Working Pressure: 220 psig
For dryers manufactured with a refrigerant other than R404A, refer to the serial
label on the dryer for refrigerat type and charge.
NOTICE
NOTICE
REFRIGERANT R404A MAX MIN CIRCUIT COMPRESSOR RATINGS FAN RATINGS
MODEL NO. VOLTS/PH/HZ WEIGHT LBS OZ FUSE AMPACITY HP RLA LRA QTY HP RLA LRA
1000HSFA400 460/3/60 2000 11 0 30 18.4 7 12.8 80.0 2 1/4 0.95 2.4
1200HSFA400 460/3/60 2300 15 0 35 23.0 9 15.7 78.5 3 1/4 0.95 2.4
1600HSFA400 460/3/60 2200 13 0 40 29.4 10.5 19.3 105.0 3 1/2 1.6 4.0
REFRIGERANT R404A MAX MIN CIRCUIT COMPRESSOR RATINGS
MODEL NO. VOLTS/PH/HZ WEIGHT LBS OZ FUSE AMPACITY HP RLA LRA
1000HSFW400 460/3/60 2000 6 8 15 11.3 5 8.6 60.0
1200HSFW400 460/3/60 2300 8 0 25 14.4 6 11.1 68.0
1600HSFW400 460/3/60 2300 11 0 35 20.2 9 15.7 78.5
