Instruction Manual for Using Products
1. Introduction
These Instruction Manual refer to ZHONGHANG ELECTRONIC MEASURING INSTRUMENTS CO., LTD.
Transducers load cells for potentially explosive atmospheres. These load cells are certified according
to ATEX Directive 2014-34/EU. Please read the whole instruction before taking load cells into service.
Never work on load cells for potentially explosive atmospheres if you do have the knowledge,
competence or authorization to do so. Load cells may only be used for their intended purpose and in
the circumstances specified. ZHONGHANG ELECTRONIC MEASURING INSTRUMENTS CO., LTD.
Transducers cannot be held liable for damage and injuries resulting from use other than those
intended. Load cells must only be used in their correct technical condition and whilst conforming to
the instructions of relevant application notes.
1.1 Product Description
Load cells convert mechanical force into an electrical signal. The element deforms elastically when
subjected to a weight or force. ZHONGHANG ELECTRONIC MEASURING INSTRUMENTS CO., LTD. has
load cells which are certified for use in a potentially explosive atmosphere. These load cells have a
special mark:
1.2 Products Labelling
1.2.1 Internal Label in English：
Standard product label (Sample)
Note1: Model and Capacity and Class. ZEMIC is the trademark of ZHONGHANG ELECTRONIC
MEASURING INSTRUMENTS CO., LTD.
Note2: The label material is polyester film and the adhesive material is acrylic latex. The overall
thickness of the label is 0.05mm. long*wide=37mm*21mm
1.2.2 External Label in English：
Note1: Model. Note2: Bar code.
