Reversing the doors
Proceed in numerical order.
1
9
1
19
17
20
14
16
13
12
15
11
Top Door
1.
Unscrew top hinge (1).
2.
Carefully remove the top door (2).
3.
Unscrew lower hinge (3).
4.
Remove plastic plugs (7 & 8).
5.
Refit top hinge (1) as lower hinge
(16) on the left hand side.
6.
Replace top door (17).
7.
Refit lower hinge (3) as top hinge
(18) on the left hand side.
Lower door
1.
Unscrew top hinge (4).
2.
Carefully remove the lower door (5).
3.
Unscrew lower hinge (6).
4.
Remove plastic plugs (9 &10).
5.
Refit hinge (4) as lower hinge (11)
on the left hand side.
6.
Replace lower door (12).
7.
Refit lower hinge (6) as top hinge
(13) on the left hand side.
Refit plastic plugs (7, 8, 9 & 10) into
the screw holes on the right hand
side (14, 15, 19 & 20).
EN
10
