≤ 17
Torx
(T)
x6
Wood
(W)
x15
Plastic Sheet
(PS)
x12
Wood
(1TW)
x3
Note: Installation step for 2, screws for connecting top plastic part should not be screwed very hard, because
of moving the plastic part easily left or right side.
5
* Spares
i
ncluded
42 mm
Top
view
*
* If the subject parts are not
included in the product you
have purchased, then it is valid
for other models.
