1. Parts location
Contents
1. Parts location ...................................................2
2. Specification ....................................................3
3. Symbols on the machine ..................................3
4. Warning labels on the machine .......................4
5. For safe operation ............................................5
6. Set up ...............................................................9
7. Fuel ................................................................13
8. Operation .......................................................14
9. Maintenance ..................................................17
10. Troubleshooting ..............................................21
11. Disposal .........................................................21
1. Muffler
2. Fuel tank cap
3. Shoulder frame
4. Shoulder belt
5. Air cleaner
6. Fuel tank
7. Spark plug
8. Fuel cock
9. Carburetor
10. Recoil starter
11. Choke lever
12. Loop handle
13. Gear case
14. Blade
15. Debris guard
16. Main pipe
17. Engine stopping switch
18. Right-hand grip
19. Wire clamp
20. Flexible shaft
21. Throttle wire
22. Throttle lever
SAFETY FIRST
Instructions contained in warnings within this manual marked
with a symbol concern critical points which must be taken into
consideration to prevent possible serious bodily injury, and for
this reason you are requested to read all such instructions care-
fully and follow them without fail.
NOTES ON TYPES OF WARNINGS IN THE MANUAL
WARNING
This mark indicates instructions, which must be followed in order
to prevent accidents, which could lead to serious bodily injury
or death.
IMPORTANT
This mark indicates instructions, which must be followed, or it
leads to mechanical failure, breakdown, or damage.
NOTE
This mark indicates hints or directions useful in the use of the
product.
