MAINTENANCE
Cleaning
To maximize fluid life, sludge collector basket(Y) and foam filter blocks(X) should be cleaned regularly.
At least once a week, lift out, drain sludge, and rinse filter element.
Changing Fluid
• Use the pump to direct the fluid into a proper container and remove all but the last 1” of solvent
using the pump.
• Open the drain (FIGURE 2(W)) located in the center of the tank bottom to allow the remaining
sludge to drain into a dirty pail.
• Wipe the tank clean when empty. Rinse the part basket, replace the drain plug, and refill the tank.
The cleaning process normally takes 10 - 15 minutes.
• Always dispose of used cleaning fluid properly. Refer to the cleaning chemical SDS (safety data
sheet) and manufacturer's package label for instructions.
If your model is equipped with an external filter it can be removed simply be unscrewing it from the
manifold:
See REPLACEMENT PARTS section for more information on replacement filter part numbers.
