Monsoon Connect Use, Care, and Installation Guide
MONSOON
CONNECT
INSERT
CORE
Features & Controls
Optional RF Remote Control
To order the RF remote control, the part number is 14000005. The blue antenna wire needs to be
extended for optimal signal. Please refer to section, Mounting the Hood, for instructions.
FCC Caution
To assure continued compliance, any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment. (Example -
use only shielded interface cables when connecting to computer or peripheral device. This device
complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. (1)
This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
Synchronization
To create a unique link between your hood and remote control please follow these steps.
1. With hood o, press and hold
on the hood until the controls display “REMOTE PAIRING”.
2. Press a button on the remote, and the remote control will be synchronized with the hood.
RF Remote Control Functions
Blower On / Speed Selection
Press to power on blower and cycle through all six blower speeds.
Blower On / Power O
By pressing , the blowers will power on at the last speed setting. Press
again and the entire hood will power o, including lights.
Delay O
Lights 1/2/3/O
Switch between light levels by pressing . Turn o the lights by cycling through
the dierent light levels.
Blower On/
Speed Selection
1
1
2
3
4
Blower On/
Power O
2
10 Min Delay O
3
Lights 1/2/3/O
4
By pressing , the blower and lights will enter Automatic Delay O mode. The
clock icon will illuminate and the controls will display “AUTOMATIC DELAY OFF”.
The blower will change to speed 1 and a 10 minute timer will begin counting
down.
