16
PRWB24C32CG Use, Care, and Installation Guide
WINE & BEVERAGE
COOLER
DUAL ZONE
PRESRV™
Installation Instructions
Installation Clearance Requirements
When installing the wine and beverage cooler under a counter, follow the recommended spacing
dimensions shown.
► For proper clearance of the electrical plug, allow at least 1” of clearance at the back as shown in
the diagram.
► An installation next to a wall will require a minimum 2-1/4” door clearance to accommodate the
Zephyr handle.
► The cabinet should allow at least 24” for the width and 34” for the height to accommodate the
wine and beverage cooler.
► The power cable is located on the back right of the unit and has a length of 72” to accommodate
multiple outlet locations.
► Once you are ready to install the unit, you must adjust the feet to level the wine and beverage
cooler.
► This refrigerator can be fully built-in to cabinetry and does not require any additional clearances
besides what is referenced below.
► The installation should allow the unit to be pulled forward for servicing, if necessary.
2-
1/4
” Min.
.niM ”43
24” Min.
1” Min.
