Installation – +RRG6SHFL¿FDWLRQ=$=
FRONT
SIDE
TOP of HOOD
TOP SUPPORT FRAME
(top view)
C/L
8 1/8”
7 9/16”
3 9/16”
13/16”
4 3/16”
8 1/4”
STANDARD
min. ducted - 31 1/2”
min. recirc. - 36”
max. - 50”
Z1C-00AZ
min. ducted - 47”
min. recirc. - 51”
max. - 80”
10 5/8”
25 9/16”
1 3/16”
11”
35 7/16”, 41 15/16”
9 7/16”
16 9/16”
5 1/4”
5 15/16”
3 1/2”
AC In
1 1/4”
C/L
C/L
1 7/8”
5 5/16”
