Ductless recirculation is intended for applications where an exhaust duct work is not possible to be installed.
When converted, the hood functions as a recirculating hood rather than an exhaust hood. Fumes and exhaust
from cooking are drawn and ltered by a set of optional charcoal lters. The air is then puried and re-
circulated back within the home.
We recommend to ALWAYS exhaust air outside of the home by employing existing or installing new duct
work, if possible. The hood is most e󰀨ective and e󰀩cient as an exhaust hood. Only when the exhaust option
is not possible should you recourse to converting the hood into a recirculating hood.
When converted to be a recirculating hood, a set of charcoal lters are required on top of its standard
aluminum mesh lter set. Order according to its part number below. The standard aluminum mesh lters are
intended to capture residue from cooking and the optional charcoal lters help to purify fumes exhausted from
cooking for recirculation.
RECIRCULATING KIT (REQUIRED IF NO DUCTING IS USED)
Kit includes charcoal lter, lter attachment clip and air diverter plate.
Hood Models Part No. Filters in pkg.
ZAZ ZRC-02AZ 2
ZLC ZRC-00LC 1
ZRM-E36DS ZRC-02RM 2
ZRM-E42DS ZRC-01RM 3
ZRE ZRC-00RE 2
1. Purchase recirculating kit per the part number above
2. Secure air diverter plate to top support frame. Open sides of air diverter plate should face left and right
to direct air through the louver holes located on the top duct cover. Run 6” ducting from top of hood and
secure to air diverter plate.
3. Remove mesh lters from hood. Install charcoal lters as referenced with the manual included with
recirculation kit.
4. Re-Install mesh lters.
5. Turn on charcoal lter change indicator on control panel. (Refer to details on page 16.) The
microprocessor in the controls will indicate the need to change the charcoal lter after 120 hours of
continuous use. Order replacement charcoal lters per the list below.
Charcoal lters must be replaced after every 120 hours of use (or approximately every 3 to 4 months
based on an average of 1 - 2 hrs. of daily cooking time).
NOTE: For more details refer to manual included with recirculation kit.
Charcoal Filter Replacements
Hood Model Part No. Qty to Order
ZAZ Z0F-C091 2
ZLC Z0F-C092 1
ZRM-E36DS Z0F-C002 2
ZRM-E42DS Z0F-C002 3
ZRE Z0F-C002 2
DO NOT WASH CHARCOAL FILTERS. Charcoal lters may need
to be changed more often depending on cooking habits.
