14
TRIANGULAR BRUSH 33 WIPER 22X22CM 34
This cotton cloth is specially devised for
the triangular brush (33).
1. Place the triangular brush (33) on the cloth (34).
2. Wrap the cloth around the brush. (picture S; Sa)
11.4 WINDOW WIPER 40
The window wiper is for easy cleaning of glass and other smooth surfaces
WARNING! When the outside temperature is around freezing point, the
glass of the window should be quickly sprayed with steam at a distance
of 10 -20 cm. Then spray the steam on the entire surface of the glass to
compensate the sudden change in temperature and to avoid pressure on
the glass surface. Sudden changes in temperature between the glass of
the window and steam may cause the glass to break.
1. Connect extension tube (32) or nozzle from flex tube (31) to window wiper
(40). Press the spring button and insert end of extension tube or nozzle
into window wiper until the spring bottom snaps into its correct position
(pictures U; Ua)
2. Spray the steam onto window from top to bottom (Picture Ua) by placing
the regulator to position 6.
3. Remove the dirt with window wiper (40).
4. After each application, clean the blade of the window wiper with a clean
cloth. Only by cleaning and applying the correct pressure to the blade is it
possible to clean the window without smudges.
11.3 SMALL ROUND BRUSH 38
NOTE: use the small brush only with inclined precision head (39).
1. Attach the small round brush (38) to the end of the inclined precision head
(39). (pictures T; Ta)
2. Connect the precision head (39) to the extension tube (32) or directly to the
flex tube nozzle (31)
3. Press the spring button and insert end of extension tube or nozzle into inclined
precision head (39) until the spring bottom snaps into its correct position.
NOTE: Very dirty windows must first be cleaned with the triangular
brush (33) or rectangular brush (36) with the cloths (34/35).
