Zero B ultimate User Manual

PARAMETERS Zero B Ultimate RO
INLET WATER CONDITIONS
ELECTRIC SUPPLY
PURIFICATION STAGES
Dimensions in mm (basic unit) L X W X H 330 mm X 320 mm X 450 mm
Weight 12 Kg.
Output flow rate 10 ltr./hr.
2
Inlet pressure (Max-Min) 0.5 to 2kg/cm
Maximum inlet water (TDS) 1300 ppm (subject to hardness of
feed water being less than 500 ppm)
Rejection of salts (TDS) 90 to 95%
Recovery of pure water 25 to 30%
Operating voltage 230 V AC +1 0% 50 Hz
-
Power consumption 30W maximum
RO booster pump 24V DC
Sediment filter 10 micron rated
RO Membrane (GDP X no.) 100 GDP X 1
Resin carbon cartridge Polyiodinated resin, polishing
bacteriostatic activated carbon
Power ON Red LED
Purifier ON Green LED (While the tank starts filling)
Auto flush timers Yellow LED (While the auto flush is on)

Zero B ultimate Specifications

General

Brand	Zero B
Model	ultimate
Category	Water Filtration Systems
Language	English
