Zero B ultimate - Installation & Maintenance; Unit Location Requirements; Hydraulic System Tightness; Ventilation Requirements

1/2” THD X 3/8” Tube
Elbow Male Connector
½” THD X ¼” Tube
Elbow Male Connector
3/8” White Tube
CPTAP
Ball Valve 3/8” X1/2” Hose
Adaptor with Silicon “O” Ring
PRE HQ Carbon Filter
Reject
Blue Tube
Drain
Transparent
Tube
Inlet Orange Tube
PREFILTER CAN BE LOCATED
AT ANY CONVENIENT LOCATION
W.R.T ULTIMATE UNIT
INSTALLATION DIAGRAM - ZERO B ULTIMATE
Ultimate
