ZERONE ZEUS-150 - Page 25

ZEUS-200S/150 ZO-OM-007
REV : 08 23 ZERONE
● Bioplar
① Double Foot Switch connection on the back of the product.
② Select the Bipolar mode and set the output(W) using UP and DOWN button.
③ Connect Bipolar Cable to Bipolar Forceps connection.
④ To activate Bipolar Coagulation, use the blue pedal of the double foot switch.
● Auto Mode & Manual Mode
It is possible to switch between Auto Mode and Manual Mode, by pressing the Bipolar
mode button and Power ON.
① Auto Mode
- After you pressed the Bipolar Mode button and turned the power on, if the system
turns to Auto Mode, the Display shows .
- Double Foot Switch, Cut in Twin Button Handle, and Coagulation are available.
② Manual Mode
- After you pressed the Bipolar Mode button and turned the power on, if the system
turns to Manual Mode, the Display shows .
- Cut, Coagulation, and selected mode in Bipolar Coagulation are available.
● Power off : Turn the electrosurgical unit OFF and disconnect the power cord from the
Receptacle(wall mains outlet).
● Make sure that the electrosurgical unit and foot switch are completely dry before
Storage.
When using Forceps. don’t activate this surgical unit until it makers contact
with a patient.
Note that bipolar TIPs should not short-circuited. each other to prevent
a direct cause of product faults.
Caution
The factory default mode of ZEUS-200S/150 is Auto Mode.
In changing Mode(Auto Mode, Manual Mode), power OFF first, press Bipolar
mode button, and power ON again.
Notice
