ZERONE ZEUS-150 - Voltage Output Graphics

ZEUS-200S/150 ZO-OM-007
REV : 08 32 ZERONE
11. Voltage Output Graphic
11.1 Pure Cutting (Load 200Ω) Max Peak Output Voltage : 315Vp
11.2 Blend1 (Load 200Ω) Max Peak Output Voltage : 325Vp
11.3 Blend2 (Load 200Ω) Max Peak Output Voltage : 340Vp
0
50
100
150
200
250
300
350
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200
Voltage(Vp)
Watt
0
50
100
150
200
250
300
350
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
Voltage(Vp)
Watt
0
50
100
150
200
250
300
350
10 20 30 40 50 60 70 80 90 100 110 120
Voltage(Vp)
Watt
