Test specifications for Enclosure port immunty to RF wireless communications equipment
Test
frequency
(MHz)
Band
(MHz)
Service
Modulation
Maximu
m
Power
(W)
Distance
(m)
Immunity
Test level
(V/m)
385
380-390
TETRA 400
Pulse modulation 18Hz
1,8
0,3
27
450
430-470
GMRS 460,
FRS 460
FM ±5 kHz deviation
1 kHz sine
2
0,3
28
710
704-787
LTE Band
13,17
Pulse modulation 217Hz
0,2
0,3
9
745
780
810
800-960
GSM 800/900,
TETRA 800,
iDEN820,
CDMA 850,
LTE Band 5
Pulse modulation 18Hz
2
0,3
28
870
930
1720
1700-1990
GSM 1800;
CDMA 1900;
GSM 1900;
DECT;
LTE Band
1,3,4,25;
UMTS
Pulse modulation 217Hz
2
0,3
28
1845
1970
2450
2400-2570
Bluetooth,
WLAN,
802.11 b/g/n,
RFID 2450,
LTE Band 7
Pulse modulation 217Hz
2
0,3
28
5240
5100-5800
WLAN
802.11 a/n
Pulse modulation 217Hz
0,2
0,3
9
5500
5785
Note: If necessary to achieve the immunity test level, the distance between the transmitting antenna and
the ME Equipmnet or ME System may be reduced to 1m test distance is permitted by IEC 61000-4-3.
a) For Some Services, Only the uplink frequncies are included.
b) The carrier shall be modulated using a 50% duty cycle square wave signal.
c) As an alternative to FM modulation, 50% pulse modulation at 18 Hz may be used because while it does
not represent actual modulation, it would be worst case.
