Zest ZQ280S2D2 - Page 13

Function
code
Name Description
Setting
range
Factory
default
F4.02 Jog Accel time
F4.03 Jog Decel time
F4.04 Accel Time 2 10.0s
F4.05 Deccel Time 2 10.0s
F4.06 Jog priority
0: invalid
1: When the VFD is running, the jog priority
is the highest
0-1 1
F4.07 Jump frequency
0.0-upper
limited
0.00Hz
F4.08 Jump frequency width 0.0-10.0Hz 0.00Hz
F5.00 FWD/REV mode
0：Two-line control mode1
1：Two-line control mode2
2：Tree-line control mode1
3: Tree-line control mode2
0-3 0
F5.01
Terminal run detection
selection at power on
0：Teminal running command is invalid when
electrified
1：Teminal running command is valid when
electrified
0-1 0
F5.02 Input X1 Function 0-26 3
F5.03 Input X2 Function 0-26 4
F5.04 Input X3 Function 0-26 12
F5.05
ZQ280:Input X4 Function
ZQ280A:RS485+
0-26 13
F5.06 0-26 8
F5 group: Digital Input and Output Parameters
Set the jog acceleration and deceleration time
0.1-999.9s
Model setting
0.1-999.9s
By setting the jump frequency and range, the
inverter can avoid the mechanical resonance
point of the load.
0：Control end idle
1：Forword rotation contrl（FWD）
2：Reverse rotation contrl（REV）
3：Three-line control
4：Forword jog control
5：Reverse jog control
6：Stop freely control
7：Externa Stop control
8：External rest signal input(RST)
9：External failure open input
10：Frequency increase control(UP)
11：Frequency decelerase control(DOWN)
12：Multi-speed selection1
13：Multi-speed selection2
14：Multi-speed selection3
15：Run command switch to terminal
16：Reserve
17：Stop DC brking
18：frequency source switch（F0.06）
19：Reserve
20：Reserve
21：Reserve
22：Count clearance signal(Fb.10 Count
function)
23：Count trigger signal(Fb.10 Count function)
24：Timing clearance signal(Fb.10 Timing
function)
25：Timing trigger signal(Fb.10 Timing function)
26：Acceleration or deceleration time selection
（Time 1 and Time 2 switch selection）
12
ZQ280:Input X5 Function
ZQ280A:RS485-
