Zest ZQ280S2D2 - FA Group: Protect Parameters

Function
code
Name Description
Setting
range
Factory
default
F9.05
Parameters self-adjustment
selections
0：No operation
1：Static self-tuning
0-1 0
F9.06
Motor stator resistance
0.001-65.535
Ω
Model setting
F9.07
Motor rotor resistance
Model setting
F9.08
Motor rotor inductance
Model setting
F9.09
Motor rotor mutual inductance
Model setting
F9.10
Reserve
F9.11
Motor no-load current Model setting
FA.00 Motor overload protection
0：Invalid
1：Valid
0-1 0
FA.01
Motor overload protection curve
coefficient
The motor overload protection factor is the
percentage of the rated current value of the
motor to the rated output current value of the
VFD.
30%-110% 100%
FA.02 Undervoltage protection level
This power parameter specifies the allowable
lower limit voltage of the DC bus when the
inverter is working normally.
150-280V
300-480V
180/360V
FA.03 Overvoltage Stall Enable
0：disabled
1：enable
0-1 1
FA.04 Over-voltage limit level
The overvoltage limit level defines the operating
voltage for overvoltage stall protection
350-380V
660-760V
375/660V
FA.05 Current limit level
The current limit level defines the current
threshold value of the automatic current limit
action, and its set value is a percentage relative
to the rated current of the VFD.
30-200% 150%
FA.06
Frequency drop rate at current
limit
0-99.99Hz/s 0
FA.07 Current limiting action selection
0：invalid
1：Acceleration and deceleration are valid,
constant speed is invalid
2：Valid for acceleration and deceleration, valid
for constant speed
0-2 0
FA.08 Overload pre-alarm level
The current threshold of the VFD overload
pre-alarm action, and its set value is a
percentage relative to the rated current of the
inverter.
120-150% 120%
FA.09 Overload pre-alarm delay
The delay time between the VFD output current
continuously greater than the overload pre-alarm
level amplitude (FA.08) and the output of the
overload pre-alarm signal.
0.0-15.0s 5.0s
FA.10
Oscillation suppression
coefficient
In general, when the motor oscillates, increase
the oscillation suppression coefficient.
0-200 30
FA.11
Amplitude suppression
coefficient
Set the maximum adjustment amount for
oscillation suppression.
0-1000 20
FA.12
Oscillation suppression lower
limit frequency
Below this frequency, oscillation suppression is
disabled.
0.0-FA.13 5.00Hz
FA.13
Oscillation suppression upper
limit frequency
Above this frequency, oscillation suppression is
disabled.
FA.12-
200.00Hz
50.00HZ
FA group: Protect Parameters
