Zest ZQ280S2D2 - FC Group: Communication Control Function Parameter

Function
code
Name Description
Setting
range
Factory
default
FB.10
Counting and Timing Modes
Ones place: Count arrival processing
0：Single-week count, stop output,
1：Single-week count, continue to output
2：Cycle count, stop output
3：Cycle count, continue to output.
Tens: reserved
Hundreds place: timed arrival processing,
0：Single-week timing, stop output
1：One-week timing, continue to output,
2：Cycle timing, stop output
3：Cycle timing, continue to output.
Thousands: reserved
000-303 103
FB.11
Counter reset value setting 0-9999 1
FB.12
Counter detection value setting 0-9999 1
FB.13
Timing time setting 0-9999s 0
FB.14
Reserve
FB.15
Reserve
FB.16
Reserve
FB.17
Reserve
FB.18
Reserve
FB.19
Reserve
FB.20
Reserve
FB.21
Reserve
FB.22
Software version Model setting
FC.00
Communication baud rate
0：1200 1：2400 2：4800
3：9600 4：19200 5：38400
0-5 3
FC.01
Modbus data format
0：(N,8,1) format 1：(O,9,1) format
2：(E,9,1) format 3：(N,8,1) format
3：(E,8,1) format 4：(O,8,1) format
6：(N,8,2) format
0-6 0
FC.02
485 communication address
It set communication address while VFD is
Modbus communication slave machine.
1-247 1
FC.03
Modbus communication overtime
fault time
0.0-600.0s 10.0s
FC.04
Reserve
FC.05
Modbus communication fault act
mode selections
0：No checkout overtime fault
1：Alarm
2：Forced stop
0-2 1
FC group：Communication Control Function Parameter
18
